Weichai Marine Diesel Generator Sets

Weichai Marine

The Weifang Power series of marine diesel engines is a mainstay in the marine power field, with remarkable influence. Thanks to its outstanding technical strength and profound R&D heritage, it has meticulously crafted a series of products with powerful performance. It offers a variety of models with different power specifications. These models, like precisely meshed gears, meet the power requirements of various vessels with great precision. Whether it is a small and nimble inland river vessel or a large-capacity offshore transport ship, the Weifang Power series of marine diesel engines can provide a continuous stream of surging power for them with suitable power models, enabling the vessels to sail smoothly.

  • Weichai Marine Diesel Generator Sets
  • Weichai Marine Diesel Generator Sets
  • Weichai Marine Diesel Generator Sets
  • Weichai Marine Diesel Generator Sets
  • Weichai Marine Diesel Generator Sets
  • Weichai Marine Diesel Generator Sets
  • Weichai Marine Diesel Generator Sets

Advantage:

  • 50HZ
  • 60HZ

1

Model

Power Current Engine model Cylinder Bore*Stroke Displacement Lubeoil Fuel Consumption Size Weight
KW KVA
CCFJ24JW 24  30  50/400 D226B-3CD 30/1500 105*120 3.117  5.52  1580*1200*1180 1130
CCFJ32JW 32  40  50/400 TD226B-3CD 40/1500 105*120 3.117  6.9  1590*1200*1180 1150
CCFJ50JW 50  62.5  50/400 WP4CD66E200 60/1500 105*130 4.5  10.25  1770*1200*1180 1290
CCFJ80JW 80  100  50/400 WP4CD100E200 90/1500 105*130 4.5  13.12  1770*1250*1210 1330
CCFJ100JW 100  125  50/400 WP6CD132E200 120/1500 105*130 6.75  21  2200*1250*1270 1640
CCFJ120JW 120  150  50/400 WP6CD152E200 138/1500 105*130 6.75  25.2  2260*1250*1270 1650
CCFJ150JW 150  187.5  50/400 WP10CD200E200 182/1500 126*130 9.726  29.21  2600*1250*1530 1950
CCFJ180JW 180  225  50/400 WP10CD238E200 216/1500 126*130 9.726  35.66  2600*1250*1550 1980
CCFJ200JW 200  250  50/400 WP10CD264E200 240/1500 126*130 9.726  40.1  2700*1250*1620 2100
CCFJ240JW 240  300  50/400 WP12CD317E200 288/1500 126*155 11.596  52.5  2730*1250*1660 2180
CCFJ300JW 300  375  50/400 WP13CD385E200 350/1500 127*165 12.54  63  2840*1250*1660 2300
Weichai Baudouin
CCFJ350JW 350  437.5  50/400 6M26CD447E200 406/1500 150*150 15.9  69  3500*1500*1800 4000
CCFJ400JW 400  500  50/400 6M26CD484E200 440/1500 150*150 15.9  84  3500*1500*1800 4100
CCFJ400JW 400  500  50/400 6M26CD506E200 460/1500 150*150 15.9  85  3500*1500*1850 4100
CCFJ350JW 350  437.5  50/400 6M33CD447E200 406/1500 150*185 19.6  67.35  3600*1500*1800 4000
CCFJ400JW 400  500  50/400 6M33CD484E200 440/1500 150*185 19.6  83.85  3650*1530*1800 4000
CCFJ400JW 400  500  50/400 6M33CD506E200 460/1500 150*185 19.6  84  3650*1530*1850 4100
CCFJ440JW 440  550  50/400 6M33CD539E200 490/1500 150*185 19.6  92.4  3700*1550*1850 4200
CCFJ500JW 500  625  50/400 12M33CD638E200 580/1500 12  150*185 39.2  105  4600*1900*2300 8000
CCFJ600JW 600  750  50/400 12M33CD748E200 680/1500 12  150*185 39.2  126  4800*1900*2300 8200
CCFJ640JW 640  800  50/400 12M33CD803E200 730/1500 12  150*185 39.2  134.4  4890*1980*2300 8300
CCFJ700JW 700  875  50/400 12M33CD902E200 820/1500 12  150*185 39.2  147  4900*2000*2350 8350
CCFJ800JW 800  1000  50/400 12M33CD968E200 880/1500 12  150*185 39.2  157.6  4900*2000*2350 8400
CCFJ900JW 900  1125  50/400 12M33CD1100E200 h000/1500 12  150*185 39.2  189  4900*2000*2350 8500

1

Model Power Current Engine model Cylinder Bore*Stroke  Displacement Lube oil Consumption Size Weight
KW KVA
CCFJ24JW 24 30 60/440 D226B-3CD1 40/1800 3 105*120 3.117 5.52 1580*1200*1180 1130
CCFJ30JW 30 37.5 60/440 TD226B-3CD1 44/1800 3 105*120 3.117 6.9 1590*1200*1180 1150
CCFJ40JW 40 50 60/440 WP4CD66E201 66/1800 4 105*130 4.5 8.2 1770*1200*1180 1250
CCFJ50JW 50 62.5 60/440 WP4CD66E201 66/1800 4 105*130 4.5 10.25 1770*1200*1180 1290
CCFJ64JW 64 80 60/440 WP4CD100E201 100/1800 4 105*130 4.5 13.12 1770*1250*1210 1330
CCFJ75JW 75 93.8 60/440 WP4CD100E201 100/1800 4 105*130 4.5 15.38 1770*1250*1210 1350
CCFJ90JW 90 112.5 60/440 WP6CD132E201 132/1800 6 105*130 6.75 18.9 2200*1250*1270 1640
CCFJ100JW 100 125 60/440 WP6CD132E201 132/1800 6 105*130 6.75 21 2200*1250*1270 1640
CCFJ120JW 120 150 60/440 WP6CD158E201 158/1800 6 105*130 6.75 25.2 2260*1250*1270 1650
CCFJ150JW 150 187.5 60/440 WP10CD200E201 200/1800 6 126*130 9.726 29.21 2600*1250*1530 1950
CCFJ180JW 180 225 60/440 WP10CD238E201 238/1800 6 126*130 9.726 35.66 2600*1250*1550 1980
CCFJ200JW 200 250 60/440 WP10CD264E201 264/1800 6 126*130 9.726 40.1 2700*1250*1620 2100
CCFJ250JW 250 312.5 60/440 WP12CD317E201 317/1800 6 126*155 11.596 52.5 2730*1250*1660 2180
CCFJ300JW 300 375 60/440 WP13CD385E201 385/1800 6 127*165 12.54 63 2840*1250*1660 2300

Looking For Business opportunity?

request a quote

contact with us

  • address:

    No.1 Xixu Road, Medical High-tech Zone, Taizhou city, Jiangsu, China

  • phones:

    +86-18652649673+86-523-86188882

  • Fax:

    +86-523-86848670

  • e-mall:

    jhfsale@jhgenerator.com

  • name:
  • e-mall:
  • phone:
  • services:

inquiry:

Watch overview

JIANGSU JIANGHAO GENERATOR SET CO., LTD.

Serving multiple data centers, mines, and factories worldwide.

As China Weichai Marine Diesel Generator Sets Manufacturers and Weichai Marine Diesel Generator Sets suppliers, Jiangsu Jianghao Generator Set Co., Ltd. focuses on the scientific research, production and service of high quality diesel and gas generator sets. The company is located in Taizhou city, close to the Shanghai port, the transportation is very convenient.
The power of the generator set produced by our company ranges from 3KW to 3000KW, covering a variety of functions: silent type, container type, mobile power station type, automatic type, multiple grid-connected type, remote centralized monitoring type, etc. Mainly using Cummins , Perkins ,Swedish Volvo ), South Korea original Doosan, Weichai , SDEC and other well-known brand engine power, and matching the world-class technology of Stamford, Leroy Somer, Marathon ,Hengsheng and domestic famous brand generator, to ensure the product quality is excellent.
Jianghao series generator sets are widely used in computing centers, industrial and mining enterprises, communications, troops, ports, highways, railways and other places, which is the ideal emergency backup power supply equipment.Jiang Hao with convincing quality and service in the generator set industry and customers to establish a good reputation, the products are exported to more than 100 foreign countries and regions.

Multiple Authorizations

Certificate
Certificate
Certificate

News & Information

Industry News

Sep 2025/09/10

Perkins Diesel Generator vs Cummins Diesel Generator: A Comprehensive Comparison

When it comes to industrial-grade power generation, Perkins and Cummins are two of the most respected names in the diesel generator industry. Both brands have a rich history of inn...

Industry News

Sep 2025/09/03

Why Are Weichai Diesel Generator Sets the Preferred Choice for Reliable Power Solutions Worldwide?

In today’s rapidly evolving industrial landscape, Weichai Diesel Generator Sets have become synonymous with durability, efficiency, and high-performance energy supply. Known for th...

Industry News

Aug 2025/08/27

Mitsubishi Series Generators: Unmatched Power and Reliability for Diverse Applications

Mitsubishi Series Generators are renowned for their exceptional performance, reliability, and innovative engineering. These generators, designed for a wide range of applications, p...

Industry News

Aug 2025/08/13

Marine Diesel Gensets: Powering Your Vessel Efficiently

Introduction Marine diesel gensets are specialized power generation units designed to supply electrical energy to ships, boats, and offshore platforms. They function as an independ...

INDUSTRY KNOWLEDGE EXPANSION

Weichai Marine Diesel Generator Sets' High Performance and Reliability

Weichai Marine Diesel Generator Sets are renowned for their high performance and reliability, serving as a vital power source for ships and offshore platforms. Leveraging independently developed engine technology, Weichai designs and manufactures a wide range of generator sets suitable for marine environments. Each generator set utilizes a meticulously designed, high-performance diesel engine, providing ample power output and stable and reliable power generation during navigation, ensuring the safe operation of the vessel.

One of the core strengths of Weichai Marine Diesel Generator Sets is the durability and high efficiency of their engines. The engine design not only prioritizes fuel efficiency and power output, but also fully considers the unique demands of the marine environment. Vessels frequently face harsh weather, salt spray, and humidity at sea, placing extremely high demands on the generator sets' corrosion resistance and vibration resistance. Weichai utilizes high-strength materials and applies anti-corrosion treatment to key engine components to ensure the generator sets' long-term, stable operation in marine environments.

Weichai Marine Diesel Generator Sets utilize advanced fuel management technology to improve combustion efficiency, reduce fuel consumption, and ensure optimal performance under various load conditions. Even at full load, the generator sets maintain low fuel consumption, enabling vessels to achieve longer voyages. Weichai generator sets also comply with International Maritime Organization (IMO) emission standards, meeting environmental protection needs, particularly the nitrogen oxide (NOx) and carbon dioxide (CO₂) emissions requirements under IMO Tier III.

Weichai's generator set intelligent technology is also a highlight. Weichai's diesel generator sets are equipped with an advanced remote monitoring system that monitors engine operating status in real time, provides data analysis, and provides fault warnings. This intelligent management system allows crew members to monitor the generator's operating status at all times, identify problems promptly, and make adjustments, thus avoiding unnecessary downtime. Furthermore, Weichai's generator sets are equipped with self-protection mechanisms that automatically adjust operating modes or issue alarms in the event of a fault or abnormality, preventing further malfunctions.

Weichai Marine Diesel Generator Sets Offer a Wide Range of Applications and Flexibility

Weichai Marine Diesel Generator Sets not only offer outstanding power performance but also strong adaptability, making them widely applicable to various types of vessels and offshore platforms. From large commercial vessels to small fishing boats and luxury yachts, Weichai can provide suitable power solutions. Different types of vessels have varying power requirements, and Weichai's generator sets not only meet these requirements but can also be customized to meet specific customer requirements.

On commercial vessels, Weichai generator sets are typically used to provide main or backup power, ensuring continuous and stable power during voyages. For cargo and container ships engaged in long-distance voyages, Weichai generator sets provide stable power output to meet the power needs of navigation, lighting, communications, and cargo handling systems. Weichai's efficient diesel engine design ensures stable operation of the generator sets under varying load conditions, and its high energy efficiency reduces fuel consumption.

Weichai generator sets also demonstrate their flexibility and adaptability for offshore vessels, such as offshore engineering vessels, fishing boats, and drilling platforms. These vessels often operate in extreme environments, placing higher demands on the durability and reliability of their generator sets. Weichai utilizes highly corrosion-resistant materials and protective designs to ensure stable operation in marine environments with high levels of salt spray and moisture. Furthermore, Weichai's generator sets feature low noise and vibration, making them ideally suited to the unique demands of offshore operations, minimizing noise pollution and vibration that could affect crew and equipment.

Weichai also offers generator sets in various power ranges, flexibly adapting to various power requirements. From small fishing vessels and cruise ships to large tankers and luxury yachts, Weichai's generator sets can be optimally configured to meet the specific needs of each vessel. Through its modular design, Weichai's generator sets can be flexibly adjusted to suit the vessel's space, power requirements, and budget, providing the optimal power solution.

Weichai Marine Diesel Generator Sets: Energy Efficiency, Environmental Protection, and Global Service Network

With increasing global environmental protection requirements, Weichai Marine Diesel Generator Sets not only prioritize performance and stability, but also significantly optimize energy efficiency and emissions. Weichai generator sets utilize advanced combustion technology and efficient engine design, which reduces fuel consumption while effectively lowering environmental pollution, particularly nitrogen oxide and carbon dioxide emissions. These generator sets comply with the International Maritime Organization's Tier III emissions standards, aligning with global green shipping and sustainable development requirements. Weichai also prioritizes reducing noise pollution from its generator sets. Especially for marine applications with stringent noise control requirements, Weichai's low-noise design significantly minimizes the impact on crew and the surrounding environment.

In addition to the environmentally friendly features of its products, Weichai also offers comprehensive after-sales service worldwide. Weichai's global service network spans multiple countries and regions, providing comprehensive services including technical support, installation and commissioning, troubleshooting, and spare parts replacement. Weichai's intelligent monitoring system allows customers to remotely monitor the operating status of their generator sets, providing real-time insights into key data such as engine performance, fuel consumption, temperature, and pressure, and providing timely fault warnings and maintenance recommendations. This intelligent management not only improves equipment operating efficiency but also reduces maintenance costs, providing customers with a more convenient and efficient user experience.

As part of Jiangsu Jianghao Generator Set Co., Ltd., Weichai's products are widely used worldwide. Jiangsu Jianghao Generator Set Co., Ltd. specializes in the research, development, production, and service of high-quality diesel and gas generator sets. The company's generator sets range from 3 kW to 3000 kW and include silent, containerized, mobile power station, automated, multi-grid parallel, and remote centralized monitoring models, meeting the diverse needs of various users.

Jiangsu Jianghao Generator Set Co., Ltd.'s generator set series are widely used in data centers, industrial mines, communications, the military, ports, highways, railways, and other fields, particularly excelling in emergency backup power needs. Jiangsu Jianghao Generator Set Co., Ltd. has established a strong global reputation for its outstanding quality and service, with products exported to over 100 countries and regions. The company's high-quality products and first-class service network have earned it extensive experience and a strong reputation in the generator set industry, providing reliable, energy-efficient power solutions to customers worldwide.
