Cummins Marine

The research, development and production of Cummins marine diesel engines started very early, making the company a pioneer in this field. Compared with other brands, their power performance is truly outstanding. With an extremely wide power range, it can deliver anywhere from a delicate 60 horsepower to a massive 6,000 horsepower. This broad power spectrum enables it to perfectly adapt to various types and sizes of vessels. Whether it's a yacht that pursues speed and comfort, a fishing boat dedicated to fishing operations, a tugboat tasked with towing heavy loads, a tractor ship responsible for traction work, a workboat for various tasks, an offshore oil platform supply vessel, or even a military and police vessel with special missions, all can obtain stable and powerful power support from Cummins marine diesel engines.

In terms of environmental adaptability, Cummins marine diesel engines demonstrate extraordinary capabilities. They can easily handle various complex water environments and changing climate conditions. Whether navigating through calm freshwater areas, sailing in saltier seawater, or facing extreme climates with high temperatures and humidity, they can always operate stably. It's worth noting that some models of diesel engines also have excellent cold-start performance. Even in cold and low-temperature environments, they can start quickly, providing a reliable guarantee for the normal operation of vessels.

In addition, Cummins' comprehensive after-sales service system is highly praised. Once customers have needs, the company can respond promptly, providing them with timely, efficient, and professional maintenance and repair services. This ensures the normal operation of vessels in all aspects, relieving customers of any concerns.

  • Cummins Marine
  • Cummins Marine
  • Cummins Marine
  • Cummins Marine
  • Cummins Marine
  • Cummins Marine
  • Cummins Marine

Advantage:

  • 50HZ
  • 60HZ

1

Model Power Current Engine model Cylinder Bore*Stroke Displacement Lubeoil Fuel Consumption Size Weight
KW KVA
Dongfeng Cummins
CCFJ30JW 30  37.5  50/400 4BTA3.9-GM47 47/1500 102*102 3.9  6.39  1650*850*1270 760
CCFJ40JW 40  50  50/400 4BTA3.9-GM47 47/1500 102*102 3.9  10.02  1740*850*1270 800
CCFJ50JW 50  62.5  50/400 6BT5.9-GM83 83/1500 102*120 5.9  12.47  1900*890*1300 1000
CCFJ64JW 64  80  50/400 6BT5.9-GM83 83/1500 102*120 5.9  15.96  1900*890*1300 1100
CCFJ75JW 75  93.75  50/400 6BT5.9-GM83 100/1500 102*120 5.9  18.71  1920*890*1300 1250
CCFJ90JW 90  112.5  50/400 6BTA5.9-GM100 100/1500 102*120 5.9  22.45  1990*890*1300 1300
CCFJ100JW 100  125  50/400 6CT8.3--GM115 115/1500 114*135 8.3  24.94  2110*860*1360 1650
CCFJ120JW 120  150  50/400 6CTA8.3-GM155 155/1500 114*135 8.3  29.93  2110*860*1360 1700
C2 Emission
CCFJ40JW 40  50  50/400 B3.9CMII64G 47/1500 102*102 3.9  8.8  1750*850*1350 950
CCFJ50JW 50  62.5  50/400 B3.9CMII82G 60/1500 102*102 3.9  10.6  1800*900*1400 960
CCFJ64JW 64  80  50/400 B5.9CMII113G 83/1500 102*120 5.9  13.88  2160*800*1300 1000
CCFJ80JW 80  100  50/400 B5.9CMII136G 100/1500 102*120 5.9  17.2  2200*800*1300 1050
CCFJ100JW 100  125  50/400 B5.9CMII156G 115/1500 102*120 5.9  21.3  2200*800*1300 1100
CCFJ120JW 120  150  50/400 L8.9CMII211G 155/1500 114*145 8.9  25.92  2640*970*1450 2000
CCFJ180JW 180  225  50/400 L8.9CMII272G 200/1500 114*145 8.9  37.8  2650*1050*1450 2250
Chongqing Cummins
CCFJ150JW 150  187.5  50/400 NT855-DM 180/1500 140*152 14  28.65  300*1050*1650 2600
CCFJ200JW 200  250  50/400 NTA855-D(M) 240/1500 140*152 14  48.94  2760*990*1790 3100
CCFJ200JW 200  250  50/400 N855-DM 240/1500 140*152 14  48.94  2760*990*1790 3100
CCFJ250JW 250  312.5  50/400 NTA855-D(M) 284/1500 140*152 14  61.18  2760*990*1790 3180
CCFJ250JW 250  312.5  50/400 N855-DM 284/1500 140*152 14  61.18  2760*990*1790 3180
CCFJ280JW 280  350  50/400 NTA855-DM 317/1500 140*152 14  68.52  2990*990*1790 3250
CCFJ280JW 280  350  50/400 N855-DM 317/1500 140*152 14  68.52  2990*990*1790 3250
CCFJ300JW 300  375  50/400 KTA19-D(M) 336/1500 159*159 19  44.8  3170*1000*1900 3750
CCFJ320JW 320  400  50/400 K19-DM 358/1500 159*159 19  49.5  3170*1000*1900 3750
CCFJ350JW 350  437.5  50/400 KTA19-D(M) 403/1500 159*159 19  49.5  3170*1000*1900 3800
CCFJ350JW 350  437.5  50/400 K19-DM 410/1500 159*159 19  49.5  3170*1000*1900 3800
CCFJ400JW 400  500  50/400 KTA19-D(M) 448/1500 159*159 19  54.2  3170*1000*1900 3950
CCFJ400JW 400  500  50/400 K19-DM 448/1500 159*159 19  54.2  3170*1000*1900 3950
CCFJ500JW 500  625  50/400 KT38-DM 560/1500 12  159*159 38  78.5  3950*1500*2500 6200
CCFJ600JW 600  750  50/400 KTA38-D(M) 664/1500 12  159*159 38  87.5  4050*1400*2550 6550
CCFJ630JW 630  787.5  50/400 K38-DM 746/1500 12  159*159 38  95.6  4050*1400*2550 6980
CCFJ630JW 630  787.5  50/400 KTA38-D(M) 814/1500 12  159*159 38  103.65  4050*1400*2600 7000
CCFJ800JW 800  1000  50/400 K38-DM 880/1500 12  159*159 38  109.4  4100*1500*2600 7000
CCFJ800JW 800  1000  50/400 KTA38-D(M) 880/1500 12  159*159 38  123.5  4150*1500*2600 7200
CCFJ980JW 980  1225  50/400 K50-DM 1097/1500 12  159*159 38  141.7  4250*1500*2600 7500

1

Model Power Current Engine model Cylinder Bore*Stroke Displacement Lubeoil Fuel Consumption Size Weight
KW KVA
CCFJ50JW 50  62.5  60/480 4BTA3.9-GM65 65/1800 4  102*102 3.9  12.53  1740*850*1270 850
CCFJ80JW 80  100  60/480 6BT5.9-GM100 100/1800 6  102*120 5.9  15.96  1900*890*1300 1100
CCFJ100JW 100  125  60/480 6BTA5.9-GM120   120/1800 6  102*120 5.9  24.94  2110*890*1360 1650
CCFJ120JW 120  150  60/480 6CTA8.3-GM175   175/1800 6  114*135 8.3  29.93  2110*860*1360 1700
CCFJ150JW 150  187.5  60/480 6CTA8.3-GM175   175/1800 6  114*135 8.3  37.41  2680*860*1790 1750
CCFJ250JW 250  312.5  60/480 NTA855-D(M) 287/1800 6  140*152 14  61.18  2760*990*1790 3180
CCFJ250JW 250  312.5  60/480 N855-DM 287/1800 6  140*152 14  61.18  2760*990*1790 3180
CCFJ280JW 280  350  60/480 N855-DM 313/1800 6  140*152 14  66.07  2850*990*1790 3250
CCFJ350JW 350  437.5  60/480 KTA19-D(M) 392/1800 6  159*159 19  84.82  3170*1000*1900 3800
CCFJ380JW 380  475  60/480 K19-DM 425/1800 6  159*159 19  95  3170*1000*1900 3850
CCFJ400JW 400  500  60/480 K19-DM 485/1800 6  159*159 19  96.94  3170*1000*1900 3950
CCFJ450JW 450  562.5  60/480 KTA19-D(M) 507/1800 6  159*159 19  109.06  3550*1000*1900 4000
CCFJ600JW 600  750  60/480 KTA38-D(M) 679/1800 12  159*159 38  146.11  4100*1500*2500 6300
CCFJ720JW 720  900  60/480 KTA38-D(M) 809/1800 12  159*159 38  170.47  4100*1500*2500 6400
CCFJ720JW 720  900  60/480 K38-DM 821/1800 12  159*159 38  180  4100*1500*2500 6400
CCFJ800JW 800  1000  60/480 K38-DM 970/1800 12  159*159 38  197.82  4100*1500*2500 7100
CCFJ900JW 900  1125  60/480 KTA38-D(M) 1007/1800 12  159*159 38  219.18  4250*1500*2500 7500
CCFJ1100JW 1100  1375    60/480 K50-DM 1291/1800 12  159*159 50  287.5  4250*1500*2500 7500
